Below are a few more examples of custom copper sheet metal chimney caps that I've made; placing primary focus on strong design w/as few seams as possible. There is also a link to see more photos and descriptions w/prices they had paid; to help give you ideas of what to request a personalized quote for.

.

Black's Copper Flue Weather-head Cap
Skiatook, Oklahoma
 (1-2/18)

This super classy project was for Kelly and Lisa Black in Skiatook, Oklahoma. They wanted us to build them a King and Queen combo crown style weather-head. This was a very interesting project to say the least. style. 437.8# total weight.

Cost breakdown for each part:
170.2 # - for the lower base in 32oz copper with the corner covers and wood
55.8 # - 2' wide X 4' tall mid section octagon flue with 2 decorative band
199.4 # for the
weather-head and crown details
= 425.4# total weight (w/o battle axe finial)
- 50.8 # wood weight
- 9.2 # SS screen weight
= 365.4# copper weight
X $28
= $10,231.20
+ $412 for the 156 copper domes installed with another 100 spare domes packed separately
+ $160 for the 8 brass knobs for the tips of the King spires with 8 PVD brass knobs sent separately
+ $600 for custom 3D Battle Axe finial
+ $125 for the finial support pipe build
+ $241 for 16 ln' of 5/4X6 ipe hardwood,
+ $104 for 8 ln' of 1X6 ipe hardwood split in half for 16 ln',
+ $240 for the 12 sq' of SS screen X $20,
= $12,113.20 sub total for this chimney caps w/o crates and freight,
+ $900 for 2 custom crates: $300 + $600,
+ $1,103.48 truck freight to residential w/liftgate service for these 2 crates,
= $14,116.68 total for the chimney cap delivered

Cost: $14,116.68 delivered in a pair of custom wood crates

Follow this link to see all 136 photos from this project:
CBD facebook photo album

.

Gustafson's Copper Weather-head Cap
Kansas City, Missouri
 (2/18)

This cute project was for their back patio fireplace flue liner weather-head made for Craig & Susan in Kansas City, MO. This is a simplified Tuscany arch style cover with a few improvements from my previous designs: tapered eave with hidden rivets in the corners, and I made a copper covered wood spacer to form this another 3" wider than their 13" wide flue liner and make a better attachment without the risk of cracking their terracotta flue liner, which was only protruding 2.5" above the top. I also used a thicker 24oz copper for the roof top cover, since there is no internal bracing.

45.9# total weight (w/o the spacer)
- 3.4# SS screen weight
- 13.6# wood weight
= 28.9# copper weight

Cost: $1,800 delivered in a custom wood crate

Follow this link to see all 21 photos from this project:
CBD facebook photo album

.

Kurtz's Copper Chimney Pots/Cap
Incline Village, Nevada
 (10-12/17)

This Chimney pot project is for a Client in Incline Village just outside Lake Tahoe, Nevada. They are made to resemble a unique project I had done back in 2004 for a local client. Although, this project is substantially larger and numerous improvements on that original design.

Cost Breakdown:

Larger 3 flue chimney
272.5# main base with 4' flues
 + 72.91# for all 3 of the
24oz copper extension flues w/20oz copper trim work

+ 52.2# for the center weather-head
 + 78.2# for the 2 outer weather-heads
= 475.81# total weight of large chimney cap
- 19.2# SS screen weight
- 63.6# wood weight
= 393.01# copper weight
X $28 (same cost as listed in the 10/12 e-mail)
= $11,004.28
copper cost

Smaller 2 flue chimney
189.35#
main base with flues, 2' flue extension, and trim
 + 49.2# for the pair of weather-heads
= 238.55# total weight of large chimney cap
 - 7.8# SS screen weight
 - 39.2# wood weight
= 191.55# copper weight

X $28
= $5,363.40
copper cost

$
5,363.40 - 2 flue chimney
 + $11,004.28 - 3 flue chimney
 + $608 for 38 ln' of 5/4X6 ipe hardwood
 + $180 for 12 ln' of 1X6 ipe hardwood split in half for 24 ln'
 + $795.80 for the 39.79 sq' of
SS screen X $20
 = $17,951.48 sub total for these chimney caps w/o crates and freight
+ $1,800 for 4 custom crates: $300 + $400 + $500 + $600

+ $1,466.01 truck freight to residential w/liftgate service for these 4 crates
= $21,217.49 total for these chimney caps

Cost: $21,217.49 delivered

Follow this link to see all 128 photos from this project:
CBD facebook photo album

.

Tulloch's Copper Chimney Cap
Salem, Oregon
 (5/17)

Frank Tulloch tells me how at 73 years young he cannot wait around to see this chimney cap patina, so he wanted us to give it a work-over ahead of time. This was the first time we had drafted out a chimney cap on the copper sheet, and then spent the next week or so with it out in the wet weather we have been having, with some added ammonia to help speed this process a bit. The total cost for this with freight to Winston-Salem, North Carolina is $4,406.70. This has a base that is to fit over a wide course of brick that is 36" X 55.5" long. The roof cover on this is 2" out past the width of the base.

Cost Breakdown:

136# total
- 18.4# SS screen weight
= 117.6# copper weight
X $25#
= 2,940 cost for the copper work
+ $483.40 for the 24.17 sq' of SS screen at $20 sq'.
+ $183 for the full week of tarnishing work and 2 dozen chemical applications
+ $350 for a custom wood crate
+ $450 estimated for truck freight

= 4,406.40 total cost delivered

Cost: $4,406.91 delivered

Follow this link to see all 23 photos from this project:
CBD facebook photo album

.

Shelton's Copper Chimney Cap
Salem, Oregon
 (4/17)

Here we built our first convex roof covered chimney cap. It is for our Client Dr. James Shelton in Salem, Oregon. The cost delivered and installed was to not exceed $6.5k. Based on the final weights the cost went down by $314.09 below the quoted ceiling cost. I had first made him a simple aluminum cover to tide him over and get a rough idea how this sort of chimney cap would look.

Cost Breakdown:

238# final weight
- 31.8# wood weight
- 28.4# SS screen weight
= 177.8# total copper weight
X $24 per #
= $4,267.20 for all the copper
+ $242.71 for 18.67 ln' of 1X6 hardwood X $13
+ $176 for 8.8 sq' of SS screen X $20
+ $100 for 12" long flue extension
+ $500 for our delivery and installation
= $6,185.91 total

We have also been contracted to replace their steel fascia gutters on their house with our exclusive K-5 style 20oz copper gutter system.

Cost: $6,185.91 delivered and installed

Follow this link to see all 79 photos from this project:
CBD facebook photo album

.

Mughal's 2 Copper Chimney Caps & Culopa
Beaverton, Oregon
 (3/17)

This is custom designed for our client Usman Mughal in Northwest Portland. With installation this will cost them about $14.4k. The inside widths are 33" X 63", 36.5" X 69.25", and 40" square.
We have also been contracted to replace their steel fascia gutters on this new house with our exclusive K-5 style 20oz copper gutter system. He may also have us provide kits to recover these sad dormers with actual copper, in stead of this steel that was painted to look like untarnished copper. An intentional fraud by the Roofing Contractor, from what I understand.

Cost Breakdown:

Largest Chimney Cap
219.6# final weight
- 32.6# wood weight
- 16.4# SS screen weight
= 170.6# total copper weight
X $28 per #
= $4,776.80 for all the copper
+ $235.69 for 18.13 ln' of hardwood X $13
+ $533.40 for 26.67 sq' of SS screen X $20
= $5,545.89 total



Smaller Chimney Cap
192.6# final weight
- 28.4# wood weight
- 14.6# SS screen weight
= 149.4# total copper weight
X $28 per #
= $4,183.20 for all the copper
+ $213.98 for 16.46 ln' of hardwood X $13
+ $427.80 for 21.39 sq' of SS screen X $20
= $4,824.98 total



Cupola
154.2 # final weight
- 26.4# wood weight
- 11.2# SS screen weight
= 116.6# total copper weight
X $28 per #
= $3,264.80 for all the copper
+ $178.23 for 13.71 ln' of hardwood X $13
+ $360 for 18 sq' of SS screen X $20
= $3,803.03 sub total
+ $900 for 36 sq' or 45.63# of copper for the skirting below cupola X $20#
= $4,703.03 total



Cost for all 3 parts
$4,703.03 for the Cupola
+ $4,824.98 for the Smaller Chimney Cap
+ $5,545.89 for the Largest Chimney Cap
+ $500 for our delivery and installation
= $15,573.90 sub total before discount
-$1,557.39 for the extra 10% volume discount with the sale of the copper gutter job
= $14,016.51 sub total
+ $350 for crane fee w/operator
= $14,366.51 grand total

Cost: $14,366.51 delivered and installed

Follow this link to see all 193 photos so far from this project:
CBD facebook photo album

.

..
.

.
